Sharp XL-1000H

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-1000H/1100H
SPEAKER BOX PARTS
901 CPNLS1008SJ01 J AR Front Panel Ass’y [XL-1000H]
901 CPNLS1008SJ02 J AS Front Panel Ass’y [XL-1100H]
902 GBOXS0010SJSA J AS Box Ass’y
903 GWAKP1017SJ01 J AP Net Flame Ass’y [XL-1000H]
903 GWAKP1017SJ02 J AP Net Flame Ass’y [XL-1100H]
904 PDUC-0002SJZZ J AE Duct Pipe
905 PGUMM0003SJSA J AD Net Catcher
906 PCOVZ1003SJSA J AG Duct Cap
907 QTANA9014SJZZ J AE Terminal
908 TSPC-0222SJZZ J AD Specification Label [XL-1000H]
908 TSPC-0232SJZZ J AD Specification Label [XL-1100H]
909 XTBSF40P12000 J AA Screw,ø4×12mm
SP1,2 RSPA00005SJ8W J AP Woofer
SP3,4 RALMB0001SJZZ J AH Tweeter
ACCESSORIES/PACKING PARTS
1 1 QACCB0001SJ00 J AW AC Power Supply Cord [For U.K.]
1 1 QACCE0001SJZZ J AH AC Power Supply Cord
[For Europe]
2 QANTL0001SJZZ J AK AM Loop Antenna
3 QANTW0002SJZZ J AH FM Antenna
4 RRMCG0031SJSB J AT Remote Control
4- 1 GCABB1064SJSA J Battery Lid,Remote Control
5 SPAKA0066SJZZ J Packing Add.,Left
6 SPAKA0067SJZZ J Packing Add.,Right
7 SPAKC0156SJZZ J Packing Case [XL-1000H]
7 SPAKC0167SJZZ J Packing Case [XL-1100H]
8 SPAKZ0031SJZZ J Pad,Accessoryes
9 SPAKZ0064SJZZ J AC Polyethylene Bag,Unit
10 SSAKA0002SJZZ J AE Polyethylene Bag,Accessories
11 TCADN0001SJZZ J AE Register Card [U.K.Only]
12 TINSE0061SJZZ J AF Operation Manual [For U.K.]
12 TINSZ0091SJZZ J AL Operation Manual [For Europe]
13 TINSE0069SJZZ J Quick Guide [U.K.Only]
14 TLABE0080SJZZ J Label,Bar Code
15 TLABN0126SJZZ J Label,Serial No. [XL-1000H]
15 TLABN0135SJZZ J Label,Serial No. [XL-1100H]
16 SPAKZ0039SJZZ J Polyethylene Bag,Speaker
17 SPAKA0068SJZZ J Packing Add.,Speaker
[Top/Bottom]
18 SPAKS0003SJZZ J Sleeve Carton,Speaker
19 TLABZ0030SJZZ J AC Label,Energy
20 ———— J – Battery (UM-4) (Not Replacement
Item) [For Europe]
21 QCNWH0006SJ01 J Speaker Cord
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~8 DCEKLV024SJ03 J – Main/Tuner/Display/Terminal/
Switch/Led/Led/Holder
(Combined Ass'y)
[XL-1000H]
PWB-A1~8 DCEKLV029SJ03 J – Main/Tuner/Display/Terminal/
Switch/Led/Lamp/Holder
(Combined Ass'y)
[XL-1100H]
1 PWB-B DCEKJV024SJ03 J – Power
PWB-C QPWBF3895AFZZ J AC CD Motor (PWB Only)
OTHER SERVICE PART
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner Disc
– 5 –
