Sharp XL-HP737H - Rear Panel; Speaker System

04/1/20 XL-HP737H(H)E1.fm
E-5
ENGLISH
XL-HP737H
TINSZA065AWZZ
General Information
Controls and indicators (continued)
! Rear panel
Reference page
1.Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3. AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4. FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5. AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . 39
7.Subwoofer Pre-output Socket . . . . . . . . . . . . . . . . . . . . . . . 40
! Speaker system
1. Tweeter
2. Woofer
3. Bass Reflex Duct
4. Speaker Wire
1
7
3
2
4
6
5
1
3
4
2
