Sharp XL-MP10H Service Manual

XL-MP10H
6 – 13
Figure 6-13 WIRING SIDE OF PWB (5/5)
AC 230 V, 50 Hz For Europe
AC 230-240 V, 50 Hz For Australia/New Zealand
Lead-free solder indication
Lead-free solder is used in this POWER PWB.
Refer to "Precautions for handling lead-free solder" for instructions
and precautions.
BR
COLOR TABLE
RD(R)
OR
YL
GR
BL
VL
GY
WH(W)
BK
PK
BROWN
RED
ORANGE
YELLOW
GREEN
BLUE
VIOLET
GRAY
WHITE
BLACK
PINK
A
B
C
D
E
F
G
H
1
23456
L104
T102
T101
F101
PT1
CNP101
C150
CNS101
BL
BR
6-9 4 - H
FROM
MAIN PWB
POWER TRANSFORMER
POWER PWB-A4
When Servicing,
Pay attention as the area enclosed
by this line ( ) is directly
connected with AC main voltage.
AC POWER
SUPPLY CORD
(246)
(248)
(248)
LINE FILTER
T200mA L 250V
321
