Sharp XL-MP10H Service Manual

XL-MP10H
1 – 2
[2] SPECIFICATIONS
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
For Europe
General
Amplifier
Tuner
CD player
Cassette deck
Speaker
Power source AC 230 V, 50 Hz
Power
consumption
Power on: 25 W
Power stand-by: 0.9 W
Dimensions Width: 160 mm
Height: 242 mm
Depth: 250 mm
Weight 2.3 kg
Output power PMPO: 30 W (total)
MPO: 15 W (7.5 W + 7.5 W) (DIN 45 324)
RMS: 10 W (5 W + 5 W) (DIN 45 324)
Output terminals Speakers: 4 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Frequency range FM: 87.5 - 108.0 MHz
AM: 522 - 1,620 kHz
Type Compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency
response
125 - 8,000 Hz (normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.35 % (DIN 45 511)
Type 10 cm full-range speaker
Maximum input
power
10 W
Rated input power 5W
Impedance 4ohms
Dimensions Width: 130 mm
Height: 240 mm
Depth: 161 mm
Weight 1.4 kg/each
■
■
■
■
■
■
For Australia/New Zealand
■ General
■ Amplifier
■ Tuner
■ CD player
■ Cassette deck
■ Speaker
Power source AC 230 - 240 V, 50 Hz
Power
consumption
Power on: 25 W
Power stand-by: 0.9 W
Dimensions Width: 160 mm
Height: 242 mm
Depth: 250 mm
Weight 2.3 kg
Output power RMS: 10 W (5 W + 5 W) (10 % T.H.D.)
Output terminals Speakers: 4 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Frequency range FM: 87.5 - 108.0 MHz
AM: 522 - 1,620 kHz
Type Compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency
response
125 - 8,000 Hz (normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.3 % (WRMS)
Type 10 cm full-range speaker
Maximum input
power
10 W
Rated input power 5W
Impedance 4ohms
Dimensions Width: 130 mm
Height: 240 mm
Depth: 161 mm
Weight 1.4 kg/each
Specifications for this model are subject to change without prior
notice.
