Sharp XL-MP10H Service Manual

XL-MP10H
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
C806 VCKYCY1EF104Z AA 0.1 µ F,25V
C807 RC-GZA107AF1C AB 100 µ F,16V,Electrolytic
C808 VCKYCY1EF104Z AA 0.1 µ F,25V
C809 VCKYCY1HB102K AA 0.001 µ F,50V
C810 RC-GZA474AF1C AB 0.47 µ F,16V,Electrolytic
C811 VCKYCY1EF104Z AA 0.1 µ F,25V
C812 VCKYCY1EF473Z AB 0.047 µ F,25V
C813 VCKYCY1EF103Z AA 0.01 µ F,25V
C814 VCKYCY1EF473Z AB 0.047 µ F,25V
C815 VCKYPA1HB563K AC 0.056 µ F,50V
C816 RC-GZA107AF1C AB 100 µ F,16V,Electrolytic
C817 VCKYCY1EF103Z AA 0.01 µ F,25V
C818 VCKYCY1EB563K AD 0.056 µ F,25V
C819 VCKYCY1EF104Z AA 0.1 µ F,25V
C820 VCKYCY1EF103Z AA 0.01 µ F,25V
C821 VCKYCY1HB472K AA 0.0047 µ F,50V
C822 RC-GZA107AF1C AB 100 µ F,16V,Electrolytic
C823 RC-GZA106AF1C AB 10 µ F,16V,Electrolytic
C824 RC-GZA106AF1C AB 10 µ F,16V,Electrolytic
C825 RC-GZA105AF1C AB 1 µ F,16V,Electrolytic
C826 VCKYCY1EF473Z AB 0.047 µ F,25V
C827 VCKYCY1EF104Z AA 0.1 µ F,25V
C828 VCKYCY1EF104Z AA 0.1 µ F,25V
C829 VCCCCY1HH100J AA 10 pF (CH),50V
C830 VCKYCY1HB104K AD 0.1 µ F,50V
C831 VCCCCY1HH100J AA 10 pF (CH),50V
C832 VCKYCY1HB104K AD 0.1 µ F,50V
C833 VCKYCY1HB104K AD 0.1 µ F,50V
C834 RC-GZA105AF1C AB 1 µ F,16V,Electrolytic
C835 VCKYCY1HB104K AD 0.1 µ F,50V
C836 RC-EZD107AF1C AC 100 µ F,16V,Electrolytic
C837 RC-EZD107AF1C AC 100 µ F,16V,Electrolytic
C838 RC-GZA107AF1C AB 100 µ F,16V,Electrolytic
C839 VCKYCY1HB104K AD 0.1 µ F,50V
C840 VCKYCY1HB104K AD 0.1 µ F,50V
C841 VCKYCY1HB104K AD 0.1 µ F,50V
C842 VCKYPA1HB101K AA 100 pF,50V
C843 VCKYPA1HB101K AA 100 pF,50V
C845 VCCSCY1HL101J AA 100 pF,50V
C846 VCCSCY1HL101J AA 100 pF,50V
C847 VCKYPA1HB101K AA 100 pF,50V
C848 RC-GZA477AF1C AC 470 µ F,16V,Electrolytic
C849 VCKYCY1EF104Z AA 0.1 µ F,25V
C850 RC-GZA477AF1C AC 470 µ F,16V,Electrolytic
C851 VCKYCY1EF104Z AA 0.1 µ F,25V
C852 VCKYCY1EF104Z AA 0.1 µ F,25V
C853 RC-GZA477AF1C AC 470 µ F,16V,Electrolytic
C854 VCKYCY1HB562K AA 0.0056 µ F,50V
C855 RC-GZA106AF1C AB 10 µ F,16V,Electrolytic
C856 RC-GZA106AF1C AB 10 µ F,16V,Electrolytic
[9] RESISTORS
JP701 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
JP801 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
JP802 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
JR302 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
JR303 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
JR304 VRS-CY1JB000J AA 0 ohm,Jumper,0.8x1.55mm,Green
R101 VRD-ST2CD271J AA 270 ohms,1/6W
R102 VRD-ST2CD271J AA 270 ohms,1/6W
R103 VRD-ST2CD100J AA 10 ohm,1/6W
R104 VRD-ST2CD100J AA 10 ohm,1/6W
R106 VRD-ST2CD100J AA 10 ohm,1/6W
R107 VRD-ST2CD100J AA 10 ohm,1/6W
R109 VRS-CY1JB101J AA 100 ohm,1/16W
R110 VRS-CY1JB152J AA 1.5 kohms,1/16W
R111 VRS-CY1JB681J AA 680 ohms,1/16W
R112 VRS-CY1JB332J AA 3.3 kohms,1/16W
R113 VRS-CY1JB332J AA 3.3 kohms,1/16W
R114 VRS-CY1JB472J AA 4.7 kohms,1/16W
R115 VRS-CY1JB122J AA 1.2 kohms,1/16W
R116 VRS-CY1JB333J AA 33 kohms,1/16W
R117 VRS-CY1JB333J AA 33 kohms,1/16W
R118 VRS-CY1JB101J AA 100 ohm,1/16W
R119 VRS-CY1JB563J AA 56 kohms,1/16W
R120 VRS-CY1JB562J AA 5.6 kohms,1/16W
R121 VRD-ST2CD332J AA 3.3 kohms,1/6W
R122 VRD-ST2CD332J AA 3.3 kohms,1/6W
R131 VRS-CY1JB682J AA 6.8 kohms,1/16W
R132 VRS-CY1JB682J AA 6.8 kohms,1/16W
R302 VRD-ST2CD100J AA 10 ohm,1/6W
R303 VRD-ST2CD104J AA 100 kohm,1/6W
R304 VRS-CY1JB104J AA 100 kohm,1/16W
R305 VRS-CY1JB104J AA 100 kohm,1/16W
R306 VRS-CY1JB100J AA 10 ohm,1/16W
[8] CAPACITORS
