Sharp XL-MP10H Service Manual

XL-MP10H
10
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[11] CABINET PARTS
201 CCABBA001SJ01 AH Rear Panel Ass'y
201- 1 -------- Rear Panel
201- 2 PCUSGA002SJSA AB Cushion,Leg
202 CDORT0010SJ04 AK CD Lid Ass'y
202- 1 -------- CD Lid
202- 2 HDECQ0109SJSA AD CD Lid Window
203 CHLDM1011SJ03 Stabilizer Ass'y
203- 1 -------- Stabilizer
203- 2 PMAGF0002AWZZ AE Magnet
204 GCABCA001SJSA AL Top Cabinet
205 GCABDA001SJSA AK Bottom Chassis
206 GCOVAA031SJSA AG Cover,Cassette Holder
207 GCOVAA002SJSA AD Cover,Remote Sensor
208 GDORFA001SJSA AF Cassette Holder
209 GITASA001SJSA AK Side Panel,Right
210 GITASA002SJSA AK Side Panel,Left
211 HDECQA001SJSA AL Front Clear Panel
212 HDECQA002SJSA AE Cassette Holder Window
213 HDECQA003SJSA AF Ring,VOLUME Knob
214 HPNLCA001SJSA AQ Front Panel
215 JBTN-A001SJSA AE Cassette Button,RECORD
216 JBTN-A002SJSA AE Cassette Button,PLAY
217 JBTN-A003SJSA AE Cassette Button,REW
218 JBTN-A004SJSA AE Cassette Button,FF
219 JBTN-A005SJSA AE Cassette Button,STOP/EJECT
220 JBTN-A006SJSA AE Cassette Button,PAUSE
221 JKNBKA001SJSA AG Button,Power
222 JKNBZ0081SJSA AD Button,CD Eject
223 JKNBZA001SJSA AF Knob,VOLUME
224 JKNBZA002SJSA AG Button,Function
225 JKNBZA003SJSA AG Button,Tuning
226 KMECBA001SJ02 Tape Mechanism Ass'y
226- 1 -------- Tape Mechanism Ass'y (Not Replacement Item)
226- 2 LANGKA003SJFW AB Bracket,Record Lver
!
227 KRPLE0022SJM2 BC CD Mechanism Ass'y
228 LANGKA002SJFW AB Bracket,PWB
229 LHLDZA069SJSA Holder,Transformer
230 LHLDW1001SJZZ AD Nylon Band
231 LHLDZA065SJSA Holder,LCD Display
232 LHLDZA066SJSA Holder,LED
233 LHLDZA003SJSA AC Lever,Record
234 MLEVP0003SJZZ AB Lever,CD Eject Button
235 MLEVPA001SJSA AD Holder,Cassette Button
236 MSPRDA012SJFJ AE Spring,CD Lid
237 MSPRDA001SJFJ AD Spring,Cassette Holder
238 MSPRDA002SJFJ AD Spring,Record Lver
239 NGERH0003SJSA AE Damper Gear
240 GCOVA1038SJSA AD Cover,Mechanism
241 PCUSG0001AWSA AD Cushion (GREEN)
242 PCUSG0004AWSA AD Cushion (BROWN)
243 PCUSGA001SJSA AB Cushion,Leg
244 PRDARA001SJFW AF Heat Sink
245 PSHEPA007SJZZ Sheet,LCD Display
!
246 QACCEA002SJZZ AH AC Power Supply Cord [For Europe]
!
246 QACCEA002SJZZ AH AC Power Supply Cord [For East Europe]
!
246 QACCLA001SJ00 AL AC Power Supply Cord [For Australia/New Zealand]
!
247 QFSHD1013CEZZ AB Holder,Fuse
!
248 QLUGP0165AFZZ AA Lug Terminal(T101,T102)
249 TLABS0042SJZZ AB Label,Laser
250 TSPC-A078SJZZ Label,Specification [For Europe/East Europe]
250 TSPC-A079SJZZ Label,Specification [For Australia/New Zealand]
601 LX-EZ0001SJFN AB Screw,M2.5x10mm
602 LX-JZA012SJFN Screw,M3x12mm
603 LX-JZA013SJFN Screw,M3x13mm
604 XHBSN20P03000 Screw,M2x3mm
605 XJBSN25P10000 Screw,M2.5x10mm
606 XJBSN30P08000 AA Screw,M3x8mm
607 XJBSN30P10000 AA Screw,M3x10mm
608 XJBY925P08000 Screw,M2.5x8mm
609 XJBY930P12000 Screw,M3x12mm
[12] SPEAKER BOX PARTS
B3CPXLMP10H Speaker Box Ass'y,L-CH/R-CH
