Sharp XL-MP110H Service Manual

XL-MP110H/MP110E
1 – 5
■
■
Rear panel
1. Speaker Terminals
2. AC Power Lead
3. FM 75 Ohms Aerial Socket
4. AM Loop Aerial Socket
5. Video/Auxiliary (Audio Signal) Input Sockets
6. Cooling Fan
7. Subwoofer Pre-output Socket
Speaker system
1. Tweeter
2. Woofer
3. Bass Reflex Duct
4. Speaker Wire
7
3
4
5
6
1
2
3
4
1
2
■ Remote control
1. Remote Control Transmitter
2. Disc Clear/Dimmer Button
3. Disc Number Select Buttons
4. Disc Random Button
5. Disc Stop Button
6. Tape Stop Button
7. Disc Track Down or Fast Reverse, Tape Rewind,
Tuner Preset Down, Time Down Button
8. Equalizer Mode Select Button
9. Extra Bass Button
10. Disc Direct Search Buttons
11. Memory Button
12. On/Stand-by Button
13. CD Button
14. Disc Pause Button
15. Tuner (Band) Button
16. Disc Play or Repeat Button
17. Tape Button
18. Tape Play Button
19. Video/Auxiliary Button
20. Tape Record Pause Button
21. Disc Track Up or Fast Forward, Tape Fast Forward,
Tuner Preset Up, Time Up Button
22. Volume Up and Down Buttons
23. Clock/Timer Button
24. MP3/WMA Display Button
21
22
23
24
6
5
4
14
16
18
20
2
3
8
10
7
17
19
13
15
12
9
1
11
