XL-S10

7 – 2

IC701 RH-iXA007SJZZ: System Microcomputer (IXA007SJ) (2/2)

IC701 RH-iXA019SJZZ: System Microcomputer (IXA019SJ) (2/2)

In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.

No.

Port Name Terminal Name Input/Output

Terminal status Option

resistor,

etc

Function

Reset Active

51 S06 S33/PE1 — LCD segment output

52 S05 S34/PE2 —

53 S04 S35/PE3 —

54 S03 S36/PE4 —

55 S02 S37/PE5 —

56 S01 S38/PE6 —

57 S00 S39/PE7 —

58 NC V3/PL6 —

59 NC V2/PL5 —

60 NC V1/PL4 —

61 COM0 COM0/PL0 — LCD common output

62 COM1 COM1/PL1 —

63 COM2 COM2/PL2 —

64 COM3 COM3/PL3 —

65 NC PWM2 Output L L “L” fixed output

66 GND VSS3 — Microprocessor power supply GND

67 VDD3 VDD3 — Microprocessor power supply +5.0V

68* NC PWM3 Output L L “L” fixed output

69 O_BK_LED P00 Output L H/L LCD Back Light output

70* NC P01 Output L L “L” fixed output

71* NC P02 Output L L

72* NC P03 Output L L

73 O_AMP_ON P04 Output L H/L AMP ON output

74 O_CD_RESET P05 Output L H/L CD RESET output

75 O_CD_CE P06 Output L H/L CD serial communication chip enable output

76 O_TU_CE P07 Output L H/L LV23002 serial communication CS output

77 O_CD_DATA P10 Output L H/L CD serial communication data output

78 I_CD_DATA P11 Input L H/L CD serial communication data input

79 O_CD_CLK P12 Output L H/L CD serial communication clock output

80 O_TU_DATA P13 Output L H/L LV23002 serial communication data output
