05_23545_D1Page 8
10 ft. x 20 ft. MAX AP Canopy - 8 Leg - Parts List - Model #23545
Quantity Part #
4 - Way Frame Connectors
6 13102
Bungee Cords
Description of Parts:
Rafter Poles, Swedge 24.4 in.
8
13104
Poles, Swedge 40.7 in. 25 13103
Cross Poles 39.5 in. 9 13107
3 - Way Frame Connectors
6 13101
1Cover 802200
8Base Feet
802916
24 10066
8Anchors
10431
Leg Poles 39 in. 8 13105
1. LAY OUT ROOF FRAME
13102 13101
13102 13101
13101
13101
13103 13103 13103
13104 13104 13104
13104 13104 13104
13103 13103 13103
13102 13101
13101
13102
13102
13103
13104
13104
13103
13102
13107 13107 13107
13107 13107 13107
13107 13107 13107
13103 13103 13103
13103 13103 13103
13103 13103 13103
FRONT
REAR
