ShelterLogic Peak Style 8' W x 8' H User Manual

Page 2
8'W x 8'H Peak Style Frame Assembly
Please read and understand instructions completely before assembly.
Layout out frame parts as shown.
ATTENTION:
FOR MISSING OR
REPLACEMENT PARTS
OR QUESTIONS, PLEASE
CONTACT
CUSTOMER SERVICE:
1.800.524.9970
CANADA 1.800.559.6175
END RIB
CROSS
RAIL
TOP RAIL
MIDDLE RIBS
END RIB
WIND
BRACE
COVER RAIL
8' W X 8' H
ITEM
NO.
DESCRIPTION
PART NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
SWED.UPRIGHT TUBE 67 3/4"X1-5/8"D. 1 END
TOP BEND TUBE 15"X1-5/8" DIA.
SIDE BEND TUBE 15"X1-5/8" DIA.
RAFTER PIPE, 42X1190XT1,4 SWG BOTH ENDS GRY
CORNER UPRIGHT TUBE 57 3/4"X1-5/8" DIA.
BEND CORNER LEG 21"X1-5/8" DIA.
CROSS RAIL 48-1/2"X1.163",PLAIN ENDS 2 H
CROSS RAIL 50-1/2"X1.163", 1 SWDG 2 HOLE
CROSS RAIL PLAIN END 47"X1-1/8" DIA.
CROSS RAIL PLAIN ENDS 45 3/4"L, 2 HOLES
CROSS RAIL SWEDGED 48 7/8"X1-1/8" DIA.
BASE FOOT, 1-3/8 STEEL, GRY
3-WAY TOP CONNECTOR
3-WAY COVER RAIL CLAMP 1 5/8" PIPE
4-WAY COVER RAIL CLAMP
WIND BRACE FLAT ENDS 62-3/4"X1-1/8"DIA.
SHELTERLOCK ANTI-RACK DEVICE 42X28MM
BOLT, CARRIAGE,1/4"X1-5/8"
BOLT, CARRIAGE 1/4"x2"
BOLT, CARRIAGE 1/4" X 3"
BOLT, LADDER RD,F/TOPCRESTS,1/4"X3 1/2"L
NUT, HEX, 1/4-20
ANCHOR, AUGER 3"X15" WITH CABLE & CLAMP
10126
10131
10132
10127
10128
02031
02030
10134
10110
10133
10113
10121
10112
10111
10135
800260
10115
10114
00670
00669
01010
00847
BOLT CAPS
24
10150
6
24
5
24
7
13
19
1
12
24
24
16
11
4
18
21/22
8
21/22
3
3
19
24
23
23
24
21/22
13
9
2
5
24
20
5
1
7
8
20
20
6
14
10
10
10
15
14
12
6
5
24
24
16
3
17
17
3
19
19
4
4
05-10DT13-0A
800465
