ShelterLogic Shed-in-a-Box 30333 User Manual

05_30333_0FPage 6
4. CONNECT REAR RIB
A. Assemble 2 Side Cross Rails using parts as shown.
B. Assemble 1 Top Cross Rail using parts as shown.
C. Connect the 2 Side Cross Rails at each ShelterLock
®
3X (800938).
D. Connect the Top Cross Rail as shown.
801277
03032
01010
802439
800607
01010
800607
801272
03032
03032
01010
800938
800938
03032
01010
800599
C1
D1
C2
D2
C1
D1
C2
D2
A
B
A
800599800599
10115
01010
800607802439
10115
01010
A B
x2 x1
