1. LAYOUT ROOF FRAME

2. ASSEMBLE ROOF FRAME

800075

800076

800077

TOP BEND CONNECTORSIDE BEND CONNECTORS

FRONT

REAR

NOTE: Ensure that parts 800075 and 800076

are installed correctly. After assembly, the

welded socket for the cross rail will be below

the bend.

Side Bend Connectors

Welded Socket

for cross rail

Bend in pipe
