2-6
THROTTLE CONTROL
Push the throttle forward to increase engine
rpm. Pull the throttle rearward to decrease
engine rpm. Always operate mower deck or
other attachment at full engine rpm.
BRAKE CONTROLS
MASTER BRAKE PEDAL
Depress the master brake pedal to stop the
unit.
The cruise control switch (OPTIONAL) will be
returned to the“OFF”position by depressing the
master brake pedal, if the cruise control switch
is in the“SET”position. Refer to page 2-8 for
cruise control switch instructions.
DUAL PEDAL TURNING BRAKE PEDALS
(OPTIONAL)
The independent brake pedals are used to
assist in turning in confined spaces at slow
speed. The right brake pedal is used to brake
the right front wheel. The left brake pedal is use
to brake the left front wheel.
PARKING BRAKE
The parking brake should be applied whenever
the CM Mower is parked or when the operator
is out of the seat.
The parking brake will be applied by raising up
the parking brake lever A.
Releasing of the parking brake is made by
lowering the lever while pressing down the
button B.
WARNING: DO NOT PARK ON AN INCLINE.
IF NECESSARY TO PARK ON AN INCLINE
BE SURE TO CHOCK THE WHEELS TO
PREVENT ACCIDENTAL ROLLING OF THE
MACHINE.
OPERATION
