Dual Pedal Turning Brakes Kit

(OPTIONAL)

The dual pedal turning brakes kit is available as

a dealer installed Option from your SHIBAURA

dealer.

AUDIBLE BACKUP ALARM

(OPTIONAL)

The audible backup alarm is available as a

dealer installed option from your SHIBAURA

dealer.

2-23
