FUNCTION OF EACH PART
3. Traveling and Mower Clutch System
①
①①
①
Gear shift lever
Used to change the traveling speed.
Vehicle speed can be selecte
speed) (4 WD) and “H” (high speed) (2 WD).
By pushing the lever forward, the speed
increases
and by pushing it rearward, the
speed decreases. Keep the lever on the low
speed side for usual operation and use the
high speed side only when traveling. When
changing the speed, stop the vehicle.
②
②②
②
Brake pedal
Used to stop the vehicle.
By pre
ssing the brake pedal, brake is applied.
A safe starting device is provided.
press the brake pedal when starting the
engine.
③
③③
③
Parking brake lever
Used to park the vehicle.
By
pressing the brake pedal fully and pulling up
the lever, the parking brake is applied.
To release the brake,
press the brake pedal and
release the brake pedal while pushing down the
lever.
●
When warming up the vehicle, be sure to
apply the parking brake.
Warning
