Shihlin electric SE3 Series Instruction Manual

 SE3 Built-in PLC terminal
 Input terminal
X number
SE3 terminal
EB362R terminal
X0
M0
X1
M1
X2
M2
X3
STF
X4
STR
X5
RES
X12
M10
X13
M11
X14
M12
X15
M13
X16
M14
X17
M15
Note: When the M2 terminal is used as an embedded PLC input terminal, the value of P.82 cannot be 41,54,57,
otherwise it will be abnormal if M2 is used as an input terminal.
 Output terminal：
Y number
SE3 terminal
EB308R terminal
EB362R terminal
Y0
SO-SE
Y2
A1B1C1
Y4
ABC10
ABC10
Y5
ABC11
ABC11
Y6
ABC12
Y7
ABC13
Y10
ABC14
Y11
ABC15
Y12
ABC16
Y13
ABC17
