Shihlin electric SE3 Series Instruction Manual

1.4 Related Parameter Description
1.4.1 Parameter Description
Number
Name
Setting Range
Content
P.32
Serial communication Baud
rate for COM1
0~5（Note 1）
1:9600bps 2:19200bps
P.812
Serial communication Baud
rate for PU
P.33
Communication protocol
selection for COM1
0~2
0: Modbus Protocol
1: Shihlin Protocol
2: PLC P.810 07-25 Communication Protocol
P.810
Communication protocol
selection for PU
P.36
COM1 station
0~254
Built-in PLC supports MODBUS protocol station
number 1~254
P.811
PU station
P.48
COM1 data length
0,1
0: 8bit
1: 7 bit
P.813
PU data length
P.49
COM1 stop bit length
0,1
0: 1bit
1: 2bit
P.814
PU stop bit length
P.50
COM1 Parity check
0~2
0: No parity check
1: Odd
2: Even
P.815
PU Parity check
P.154
COM1 Modbus format
0~5
0:1、7、N、2 (Modbus, ASCII)
1:1、7、E、1 (Modbus, ASCII)
2:1、7、O、1 (Modbus, ASCII)
3:1、8、N、2 (Modbus, RTU)
4:1、8、E、1 (Modbus, RTU)
5:1、8、O、1 (Modbus, RTU)
P.817
PU Modbus format
P.780
PLC action
0~2
0: PLC function is invalid
1: The PLC function is valid, and the PLC RUN signal
comes from the external terminal input signal or
P.781.
2: The PLC function is valid, and the PLC RUN signal
comes from the external terminal input signal.
P.781
Control PLC RUN/STOP
0,1
0: No effect
1: If 10-55(P.780) = 1, PLC will run.
P.782
Erase PLC program
0,1
0: invalid
1: Erase the PLC program, the parameter value is 0
after the erase is successful.
P.783
PLC component monitoring
selection
0~326
0: Invalid monitoring
1~326: Corresponding to different types of
component monitoring.
P.784
PLC component monitoring
value
Read only
The parameter value is the state of the component

Shihlin electric SE3 Series Specifications

General

Brand	Shihlin electric
Model	SE3 Series
Category	Inverter
Language	English
