Parameter Description
Parameter Description
86
5.21 Multi-function Output (P.40, P.64, P.74, P.85, P.120 and P.187)
P.40 “Multi-function output terminal
pattern”
P.64 “Pulse output selection”
P.74 “10X output selection”
P.85 “Function selection for
multi-function relay”
P.120 “Output signal delay time”
P.187 “FM calibration parameter”
< Setting >
• When set different value to P40/P.85, the function of the SO-SE (SO function)/A-B-C terminal is
below:
Parameter
function
P.40/P.85
0
RUN (Inverter running): Signal will be output when the output frequency is equal to
or higher than the starting frequency.
1
SU (Up to frequency): Signal will be output once the output frequency has reached
the set region of frequency.
2
FU (Output frequency detection): Signal will be output once the output frequency
has reached or exceeded the detection frequency set.
3
OL (Overload detection): Signal will be output once the current limit function is
triggered. (About OL2 detection, please refer to over torque detection selection
P.260)
4
OMD (Zero current detection): If the output current percentage of the inverter is less
than the set value of P.62, and lasts for the pre-defined time (the setting value of
P.63), OMD will output signal.
5
ALARM (Alarm detection): Alarm detection
6
PO1 (Section detection): At the programmed operation mode, PO1 signal will be
output in the end of each section.
Parameter
Factory Setting
Setting Range Remarks
40 0 0~12, 17,18 ---
64 0 0, 1
P.64=0, P.74=0：SO function
P.64=1, P.74=0：FM function
P.64=1, P.74=1~10：10X function
74 0 0~10
85 5 0~12, 17,18 ---
120 0s 0~3600s ---
187 220 0~9998
The calibrating values, therefore the default value
for each machine may differ slightly.
