70
Data Content
Tag Entries
Remarks
Section
Key
Data Tag
（4 byte）
Type of Data
（2 byte）
Data Count
（4 byte）
Gamma correction
factor
0x2020,
0x2006
2
1
Setting value: 30 to 300
(1/100)
Brightness
0x2020,
0x2007
2
1
Setting value: -100 to 100
Contrast
0x2020,
0x2008
2
1
Setting value: 50 to 200
(1/100)
REC_INFO
Recording mode (on UI)
0x3030,
0x3001
2
1
Setting value:
0: Internal
1: External STANDBY
2: External TRIG
3: External SEPARATE
4: R-External STANDBY
5: R-External TRIG
6: R-External SEPARATE
7: External SYNCIN
8: R-External SYNCIN
Synchronized recording
mode (on UI)
0x3030,
0x3002
2
1
Setting value:
0:OFF
1:Master
2:Slave
Trigger points (on UI)
0x3030,
0x3003
2
1
Setting value: 2 to 256
Trigger mode
0x3030,
0x3004
0
16
Setting value: (Character
string)
Internal
E-trig
E-stdby
E-sep
Sync
Recording mode
0x3030,
0x3005
0
16
Setting value: (Character
string)
CFP
BFP
BHP
UBFA5
UBHA5
UBHA10
UBHA20
Recording frame count
0x3030,
0x3006
2
1
Setting value: 1 to 256
Recording speed
0x3030,
0x3007
0
24
Setting value: (Character
string)
100 to 16666670 (in 10 ns
steps of 1 ns units)
Recording exposure
time
0x3030,
0x3008
0
24
Setting value: (Character
string)
200 to 10000000 (in 10 ns
steps of 1 ns units)
Trigger input logic
0x3030,
0x3009
2
1
Setting value:
0:NEG
1:POS
Trigger input delay
setting
0x3030,
0x300A
0
24
Setting value: (Character
string)
0 to 9999999990 (in 10 ns
steps of 1 ns units)
Frames after trigger
0x3030,
0x300B
2
1
Setting value: (Character
string)
1 to 256
Standby OFF input
logic
0x3030,
0x300C
2
1
Setting value:
0:NEG
1:POS
