71
Operating
Camer
a
High-Speed Video Camera
HPV-X2
Data Content
Tag Entries
Remarks
Section
Key
Data Tag
（4 byte）
Type of Data
（2 byte）
Data Count
（4 byte）
Standby OFF input
delay setting
0x3030,
0x300D
0
24
Setting value: (Character
string)
100 to 9999999990 (in 10 ns
steps of 1 ns units)
Synchronized (internal)
circuit delay setting
0x3030,
0x300E
0
24
Setting value: (Character
string)
0 to 100 (in 10 ns steps of 1
ns units)
Synchronized (output)
circuit delay setting
0x3030,
0x300F
0
24
Setting value: (Character
string)
0 to 100 (in 5 ns steps of 1
ns units)
PortAuxout1Mode
AUXOUT1 mode
0x3030,
0x3010
2
1
Setting value:
0:EXPOSE REC
1:EXPOSE LIVE
2:EXPOSE BOTH
3:EXPOSE STANDBY
4:EXPOSE TRIG
5:EXPOSE END
6:TRIG STANDBY
7:TRIG TRIG
8:STATUS STANDBY
9:STATUS TRIG
10:STATUS REC
PortAuxout1Polarity
AUXOUT1 logic
0x3030,
0x3011
2
1
Setting value:
0:NEG
1:POS
PortAuxout1Delay
AUXOUT1 delay time
0x3030,
0x3012
0
24
Setting value: (Character
string)
0 to 9999999990 (in 10 ns
steps of 1 ns units)
AUXOUT1 signal
width
0x3030,
0x3013
0
24
Setting value: (Character
string)
50 to 10000000 (in 10 ns
steps of 1 ns units)
PortAuxout2Mode
AUXOUT2 mode
0x3030,
0x3014
2
1
Setting value:
0:EXPOSE REC
1:EXPOSE LIVE
2:EXPOSE BOTH
3:EXPOSE STANDBY
4:EXPOSE TRIG
5:EXPOSE END
6:TRIG STANDBY
7:TRIG TRIG
8:STATUS STANDBY
9:STATUS TRIG
10:STATUS REC
PortAuxout2Polarity
AUXOUT2 logic
0x3030,
0x3015
2
1
Setting value:
0:NEG
1:POS
PortAuxout2Delay
AUXOUT2 delay time
0x3030,
0x3016
0
24
Setting value: (Character
string)
0 to 9999999990 (in 10 ns
steps of 1 ns units)
PortAuxout2Pulse
AUXOUT2 signal
width
0x3030,
0x3017
0
24
Setting value: (Character
string)
50 to 10000000 (in 10 ns
steps of 1 ns units)
