https://shimano-steps.com/
198 199
https://shimano-steps.com/
E6000 Series
E6000 MANUALE8000 CONCEPT E8000 MANUAL E6000 CONCEPT
SW-E6000
Assist/Shift Switch
Cord Band A×2
Cord Band B×1
1
2
ITEM
NO.
SHIMANO
CODE NO.
DESCRIPTION
1 Y70J000B0 Fixing Bolt M4
2
Y7EU98010 Cord Band Unit
Nov.-2015-3764B
© Shimano Inc. H
SM-DUE01
Light Adapter
ITEM
NO.
SHIMANO
CODE NO.
DESCRIPTION
1 Y70P03000 Unit Fixing Screw M3
A: Same parts.
B: Parts are usable, but differ in materials, appearance, finish, size, etc.
Absence of mark indicates non-interchangeability.
Nov.-2015-3765A
© Shimano Inc. H
