E6000 MANUALE8000 CONCEPT E8000 MANUAL E6000 CONCEPT
Shift Switch/Assist Switch
<SW-E6000/SW-E6010>
SW-E6000
Series SHIMANO SHIMANO SHIMANO SHIMANO
Model no. SW-E6000 SW-E6000 SW-E6010-L SW-E6010-R
Switch Type - - - -
Color
1 Gray Gray Standard Standard
2 Black Black - -
3 - - - -
Usage For assist * For SEIS shift For assist For SEIS shift
Right SW - X - X
Left SW X - X -
Switch numbers (pcs) 3 3 3 3
Master unit - - - -
Firmware update by E-tube Project X X X X
E-tube port (pcs) 0 0 0 0
E-tube connector (pcs) 1 1 1 1
SW-E6010-R
System On-Off - - - -
Assist Mode Change X - X -
Display change X * X X X
Automatic/Manual Change - * X - X
Light On-Off * X - * X -
Multiple input
2 step - * X - -
Hold - - - ** X
Note
* Set by E-tube
project
* Set by E-tube
project
* Set by E-tube
project
** Available for RD
Adapter for DC light
<SM-DUE01>
SM-DUE01
Series SHIMANO SHIMANO
Model no. SM-DUE01 SM-DUE01
Color
1 Standard Standard
2 - -
3 - -
Type For DC light For DC light
Cables for lights
With *X -
Without - X
Front light X X
Rear light X X
Water proof connector DU side DU side
Wire holder - -
Note
*Cable length:
1600 mm
Crankarm
<FC-E6010/FC-E6000>
FC-E6010
Series SHIMANO SHIMANO
Model no. FC-E6010 FC-E6000
Color
1 Black Gray
2 Gray Black
3 - -
Crank arm type
Hollow Tech - -
Solid X X
Q factor (mm) 213 189.6
Chain case compatible X X
Crank arm length
(mm)
175 X X
170 X X
Others - -
Crank arm
Material Aluminum Aluminum
Finish Painted Painted
FC-E6000
BB Type Square type Square type
Note
Chain
<CN-HG701-11/CN-E6090-10/CN-E6070-9/CN-HG71>
CN-E6090-10
Series SHIMANO SHIMANO SHIMANO SHIMANO
Model no. CN-HG701-11 CN-E6090-10 CN-E6070-9 CN-HG71
Type HG-X11 HG-X 10-speed HG 9-speed HG
E-Bike RD system compatible X X X -
Pin link plate SIL-TEC SIL-TEC Gray Silver
Roller link plate SIL-TEC SIL-TEC Gray Gray
Roller - - - -
Chromizing treatment link pin X X X X
Hollow pin - - - -
Average weight (114 links) 257g 276g 276g 324g
Note
