Installation/removal

Electric wires

1. Set the plug of the electric wire to the TL-EW300.

If there is an alignment tab on the plug of the electric wire, check the shape of the

E-TUBE port you are trying to connect to, and set it aligned with the alignment tab.

Without alignment tab on plug

Groove

Guide

Groove

Guide

Alignment tab

With alignment tab on plug
