55
Maintenance
Gear shifting adjustment when using junction [A]
1. <▲><▼> (return the setting value to [0]) ⇒ <↑><↓> (select [OK]) ⇒
<F>
*
Switch unit integrated type: <
▲><
▼> (return the setting value to [0])
⇒ <A>
Clamp band type cycle
computer example
(SC-E7000)
Bracket installation type cycle
computer example (SC-E6100)
Switch unit integrated type
cycle computer example
(SC-E5000)
2. Try gear shifting operations.
Press <▲><▼> while turning the crank to perform gear shifting, and confirm that the
adjustment has changed. Refer to step 4 in “Adjusting when the setting value is [0]” and
adjust according to the symptom.
3. Finally, ride the bicycle and try shifting gears to check that the
abnormal noise or unusual feel has been resolved.
Gear shifting adjustment when using
junction [A]
Switch the junction [A] to the adjustment setting mode, and adjust gear shifting for the
electronic gear shifting rear derailleur.
• A switch unit configured as a shifting switch is required to set this.
• For internal electronic gear shifting, gear shifting can be adjusted from E-TUBE PROJECT. For
details, refer to the user's manual for E-TUBE PROJECT.
• For the procedure for operating the main power, refer to the “SHIMANO STEPS user's
manual.”
• Operations using the junction [A] button and switch unit are indicated using the following
notation. Refer to the user's manual for details on the switches of the switch unit.
Notation Operation
<B> Indicates an operation for pressing a button.
