16
INSTALLATION
Brake hose
Brake hose
For information on installing the brake hose, refer to the brake section of General Operations.
Make sure that the calipers and levers are in the positions shown in the illustrations.
(A)
Brake caliper
(B)
Brake lever
NOTE
•
The installation position of the brake hose
differs depending on the model.
•
Do not let the brake hose become twisted
when installing it.
(B)(A)
Overview of the easy hose joint system
For information on how to install and replace the brake hose, refer to the brake section of General Operations.
(A)
(B)
(D) (E)
(C)
(F)
(A)
Brake caliper
(B)
Hose cap
(C)
Seal plug
(D)
Hose connection port
(E)
Brake lever
(F)
Stopper
To Next Page
