MAINTENANCE
Adding Shimano genuine mineral oil and bleeding air
2
(C)
(B)
(A)
Remove the upper bleed screw and
O-ring and insert the oil funnel.
(A)
Bleed screw
(B)
O-ring
(C)
Oil funnel
TECH TIPS
Do not insert the oil stopper at this time.
3
(A)
(B)
Set a 7mm socket wrench in place, fill
the syringe with oil, connect a tube to
the bleed nipple, and then loosen the
bleed nipple by 1/8 of a turn to open it.
Push the piston of the syringe to add oil.
The oil will start coming out from the oil
funnel.
Continue adding oil until there are no
more air bubbles in the oil that is coming
out.
(A)
Bleed nipple
(B)
7mm socket wrench
