4. INTERCONNECTION VM-5S
-16-
• Be sure to observe the following cautions at the time of interconnection.
Note No.
in drawing
Caution
1
Use 2-wire twisted pair shielded cable with AWG. No. 16 to No. 20 (1.25 mm
2
to 0.5 mm
2
) for cabling between the monitor and the magnetic pickup. Do not
wire the cables together in high tension ducts.
2
Connect the shielded wires to the COM terminal.
Keep the unshielded portion of cables at connecting parts as short as possible.
(less than 100mm recommended.)
3 Do not connect the shielded wires to the connector shell.
• In the case of the input signal from a magnetic pickup, the output voltage (pk-pk) of
the magnetic pickup varies depending on the size of gear teeth, the set gap, rotation
speed, etc., and under certain conditions may become high voltage. Therefore, stay
within a range in which the output voltage of the magnetic pickup does not exceed
the monitor input voltage range (100Vpk-pk).
• Make sure to turn the power off before wiring work to prevent accidents due to
electric shock.
Warning
Mandantory
Mandatory
To Next Page
General
