9. MAINTENANCE VM-5S
-71-
9-6 REPLACEMENT OF ALUMINUM ELECTROLYTIC CAPACITOR
• Aluminum electrolytic capacitors are used on the main board, which have a limited
life. Their service life varies according to the conditions of use, but for preventive
maintenance it is recommended to check the capacitors listed below in 5-year cycles
for characteristic deterioration and replace them as necessary.
Replacement by SST is recommended.
Main Board
Component Type Manufacturer Q’ty
luminum electrolytic capacitor
C206, C207, C208
UPJ1E101M Nichicon 3
Isolation Card
Component Type Manufacturer Q’ty
Aluminum electrolytic capacitor
C1
UPJ1C471M Nichicon 1
• To remove or install the monitor, proceed according to the instruction manual of the
instrument rack. Failure to turn off the power before pulling the monitor unit out of, or
inserting it into the rack will result in serious damage and accidents.
• Do not touch the main board with bare hands.
Mandatory
Prohibition
To Next Page
