Shire Command post - Page 19

05
Align the view port surround level with the edge of the aperture.
Attach the long pieces with 3 screws each and 1 screw for the short piece
GB-IE
3mm
A0097 A0097
A0095
A0095
A0094 A0094
Sm view port surround
(A0094)x02
44mm
20mm
view port spacer
(A0095)x02
44mm
20mm
view port surround
(A0097)x02
44mm
20mm
50mmScrew
(A0557)x14
50
End panel
(A0556) x01
Lg front panel
(A0562)x01
19
