06
The view port shutters fit inside the surrounds fitted in step 05 and open outwards and downwards.
Align the view port shutter level with the edge of the aperture so the loose edge of the hinge is against
the edge of the surround below then fix with 14 screws for the long hinge and 10 for the short one.
Attach a “D” handle with 4 12mm black screws in the middle of the shutter.
Repeat with the other shutter,
3mm
GB-IE
Hinge A0102
Step 12
x01
Step 12
x01
Black D handle
(A0089)x02
25mmScrew
(A0032)x24
12mm Black Screw
(A0029)x08
12
80mm
20mm
LG view port shutter
(A0096 step11)x01
80mm
20mm
SM view port shutter
(A0093 step11)x01
20
To Next Page
