Model W1702 Machine Specifications, Page 1 of 3
MODEL W1702
3 HP SHAPER
Product Dimensions
Weight.......................................................................................................... 352 lbs.
Width (side‐to‐side) x Depth (front‐to‐back) x Height........................ 30‐1/2 x 28‐1/4 x 39‐1/2 in.
Footprint (Length x Width).............................................................................. 20 x 21 in.
Shipping Dimensions
Type.................................................................................................... Cardboard Box
Content........................................................................................................ Machine
Weight.......................................................................................................... 353 lbs.
Length x Width x Height........................................................................... 26 x 31 x 41 in.
Electrical
Power Requirement.................................................................... 220V, Single‐Phase, 60 Hz
Prewired Voltage................................................................................................. 220V
Full‐Load Current Rating......................................................................................... 12A
Minimum Circuit Size............................................................................................. 20A
Connection Type......................................................................................... Cord & Plug
Power Cord Included.............................................................................................. Yes
Power Cord Length............................................................................................... 6 ft.
Power Cord Gauge............................................................................................ 14 AWG
Plug Included........................................................................................................ No
Recommended Plug Type........................................................................................ 6‐20
Switch Type............................................................ Magnetic Switch w/Overload Protection
Motors
Main
Type......................................................................... TEFC Capacitor‐Start Induction
Horsepower................................................................................................. 3 HP
Phase.............................................................................................. Single‐Phase
Amps.......................................................................................................... 12A
Speed.................................................................................................. 3450 RPM
Power Transfer ..................................................................................... Belt Drive
Bearings............................................................... Shielded & Permanently Lubricated
