Shure Legendary Performance SVX User Manual

11
SVX
Working Range
Note: Actual range depends on RF signal absorption, reflection
and interference.
HI power mode
75m(250ft)(LineofSight)
LO power mode
18m(60ft)(LineofSight)
Audio Frequency Response
50–15000Hz(Note:Dependentonmicrophonetype)
Modulation
FM,Ref.±48kHzdeviationwith1kHztone
Total Harmonic Distortion
<0.5%
Dynamic Range
90dB,A-weighted,typical
Operating Temperature Range
-10°C(0°F)to50°C(122°F)(Note:Batterycharacteristics
may limit this range.)
Transmitter Audio Polarity
Positive pressure on microphone diaphragm produces positive
voltageonpin2(withrespecttopin3ofXLRoutput)andthetip
ofthe6.35mm(1/4-inch)output.
SVX1
Audio Input Level (maximum)
MIC setting
−15to−7dBV
LINE setting
1to9dBV
Gain Adjustment Range
8dB
Input Impedance
MIC setting
16kΩ
LINE setting
120kΩ
RF Output Power
10 mW (dependent on applicable country regulations)
Dimensions
108mmx64mmx19mm(HxWxD)
Weight
90 g (without batteries)
Housing
MoldedABS
Power Requirements
2 "AA" size alkaline or rechargeable batteries
Battery Life
up to 10 hours
SVX2
Audio Input Level (maximum)
−20dBV
Input Impedance
22kΩ
RF Output Power
dependent on applicable country regulations
HI power mode
10 mW maximum
LO power mode
1 mW maximum
Dimensions
254 mm X 51 mm dia. (10 X 2 in.)
Weight
270 g (10.2 oz.) (without batteries)
Housing
MoldedABS
Power Requirements
2 "AA" size alkaline or rechargeable batteries
Battery Life
up to 10 hours (alkaline)
SVX4/ SVX88
Dimensions
SVX4
32mmX168mmX104.5mm
SVX88
32mmX256mmX104.5mm
Weight
SVX4
245 g (8.5 oz.)
SVX88
381g(13.5oz.)
Housing
MoldedABS
Audio Output Level
Ref. ±48 kHz deviation with 1 kHz tone
XLR connector into 100 kΩ load
−16dBV
6.35 mm (1/4") connector into 100 kΩ load
−22dBV
J9 Audio Output Level
Ref. ±26 kHz deviation with 1 kHz tone
XLR connector into 100 kΩ load
−21dBV
6.35 mm (1/4") connector into 100 kΩ load
−27dBV
Output Impedance
XLR connector
600Ω
6.35 mm (1/4") connector
600Ω
Sensitivity
-105dBmfor12dBSINAD,typical
Power Requirements
(supplied by external power supply)
SVX4:
12–18VDC@130mA
SVX88:
12–18VDC@220mA
