1
Guitar systems include:
• PGX1 bodypack transmitter
• 1/4” to mini 4-pin guitar
cable
PGX4 Receiver Features
Back Panel
System Components
Front Panel
⑦ ACadapterjack
⑧ Adaptercordtie-off
⑨ XLRmicrophoneoutputjack
⑩ 6.35mm(1/4”)instrumentlev-
eloutputjack(unbalanced).
All systems include:
• PGX4 receiver
• 2 AA batteries
• Power supply
• User guide
Vocalist systems include:
• MicrophoneHead(choiceof
PG58,SM58
®
,SM86,Beta
58A
®
orBeta87A)
• PGX2 handheld transmitter
• Microphone clip
Lavalier, Headworn, and
Instrument systems
include:
• PGX1 bodypack transmitter
• Microphone(choiceof
WL93,WL185,PG30or
Beta98H/C™)
① audioLED
Indicatesstrengthofincomingaudiosignal:
greenfornormal,amberforstrongandred
forclipping.
② LEDScreen
Displaysgroupandchannelsetting.See
“SingleSystemSetup”fordetails.
③ channel button
Changes group and channel setting. See
“SingleSystemSetup”fordetails.
④ readyLED
Indicates system ready and receiving an RF
signalfromthetransmitter.
⑤ Infrared(IR)port
SendsIRsignaltotransmitterforsync.
⑥ sync button
Press to synchronize transmitter with
receiver group and channel settings.
⑥
INSTRUMENT OUTMIC OUT
⑦
⑧
⑨
⑩
