Shure QLXD2 Service Manual

T h e t r a n s m i tt e r i s b u i l t i n e i g ht boa r d g r o u p s ( A - J ) w h i c h a r e s e t i n s o ft w a r e t o be h a v e a s a s pe c i f i c ba n d f o r s a l e . T h e
t r a n s m i tt e r m a y be r ep r og r a mm ed t o a d i ff e r e nt ba n d w i th o ut r e tun i n g o n a t e s t f i x tu r e .
G r o u p A : 470 -
G r o u p B : 534 - H 50 , H 51 , H 52 , H 53
G r o u p C : 572 - , J 51
G r o u p D : 606 - , K 52
G r o u p E : 632 - L51 , L52 , L53
G r o u p F : 710 - , P 52
G r o u p G : 794 - 806
G r o u p H : 823 - S 50
G r o u p J : 925 -

Shure QLXD2 Specifications

General

RF power	1.1 mW
Form factor	Handheld transmitter
Antenna type	Built-in
Display type	LCD
Compatibility	Shure QLXD4 Digital Wireless Receiver
Product color	Black
Average latency	2.9 ms
Built-in display	Yes
Housing material	Metal
Security algorithms	256-bit AES
Maximum outdoor range	100 m
Operating frequency type	Ultra High Frequency (UHF)
Radio Frequency (RF) range	606 - 670 MHz
Operating temperature (T-T)	18 - 50 °C
Microphone frequency response	30 - 20000 Hz
Total Harmonic Distortion (THD)	0.1 %

Weight and Dimensions

Width	51 mm
Height	256 mm
Weight	347 g
