Shure SM7dB User Manual

Shure Incorporated
8/12
Install or Remove the Stand Adapter
To mount the microphone on a 3/8 in. stand, insert the included brass stand adapter and tighten it with a coin or screwdriver.
Important: Make sure that the slots on the adapter face outward.
Specifications
Type
Dynamic (moving coil)
Frequency Response
50to20,000Hz
Polar Pattern
Cardioid
Output Impedance
Preamp engaged 27Ω
Bypass mode 150Ω
Recommended Load
>1kΩ

Shure SM7dB Specifications

General

Type	Dynamic
Frequency Response	50 Hz to 20 kHz
Output Impedance	150 ohms
Connector	XLR
Switchable EQ	Yes
Built-in Preamp	Yes
Polar Pattern	Cardioid
Built-in Preamp Gain	28 dB
Weight	765 grams
Sensitivity	-59 dBV/Pa (1.12 mV) at 1 kHz
