Shure ULX - Technical Details; Wiring Diagram; Specifications

Shure Incorporated
25/31
Wiring Diagram
Specifications
RF Carrier Range
470,000–865,000MHz
Working Range
100m (300ft) typical
Audio Frequency Response
25Hz
– 15kHz, ±2dB
Modulation
±38 kHz deviation compressor-expander system with pre- and de-emphasis
Dynamic Range
>100dB, A-weighted
Image Rejection
80dB, typical
