ESA ESTRO - E7014P rev. 02 - 03/05/17
www.esapyronics.com
32
OVERALL DIMENSIONS
Pos. Elements
A Fastening connectins for transformer
C Not used
D Not used
E - E Not used
F Shoulder screw for earthing
G - G
Mounting plate for back collar
(tube ½”) – thread M6
Preformed holes Diameter mm Cable
1 19 PG11 - M20x1,5
2-3-4-5-12 16 PG9 - M16x1,5
6-8-10-11 * 16 PG9 - M16x1,5
7-9 * 19 PG11 - M20x1,5
120
G
5
F
3
1
4
2
G
E E
9
A
6
8
11
7
10
A
D
C
7
57 33 110
20 16 21 21 38
7 4
19 18.5 18.5 18.5 23 22.5
8
20 21.5 18.5 18.5 21.5 20
96
50 46
200
A A
12
17
1
* The mounting of the transformer precludes the possi-
bility of using the steps of cables 6 ÷ 11
The installation of expansion cards, precludes the possibility to mount the transformer inside ESA ESTRO and vice-
versa; in this case it necessary to use the ESA TRAFO box to contain the ignition transformer (E5004).
D7014P21
Fixing holes
internal base view
base front
