SiAECOSYS VOTOL EM User Manual

SiAECOSYS V2
15
2.1：Parameters setting for sports mode(S gear)
2.2.1 、 Bus bar current setting: According to the controller type current corresponding to the selection,
absolutely no over current is allowed.
VOLTAGE
MODEL
EM-30
S
EM-50
EM-50S
EM-100
EM-100S
EM-150
EM-150S
EM-200
EM-300
48-60V
35A
50A
55A
100A
----
200A
----
320A
550A
72V
35A
50A
55A
100A
150A
200A
250A
320A
550A
84V
33A
50A
50A
100A
----
180A
----
96V
----
45A
50A
80A
----
130A
----
250A
500A
2.2.2、Sport mode flux weakening value：Flux weakening value for S gear: the parameter value is <3000, and
the vehicle speed is adjusted according to the motor parameters. BOOST weak magnetic value> high speed
weak magnetic value
2.2.3、Auto exit function: tick to jog key / uncheck to long press key, select one from two.
2.2.3.1、Check to make the jog effective. The weak magnetic time enters the exit and can be adjusted.
2.2：Downhill electric brake assist：start by select “HDC Enable”, downhill electric brake assist (slow down
in steep slopes) function. Enable electric brake by enter minimum speed, if less than the speed, the
function will be invalid.
2.2.1、Downhill brake assist function: the speed of entering downhill brake assist function is set according
to the actual road test speed standard according to the motor parameters.
2.2.2、Note: The drum motor is not suitable for use, resulting in loose motor shaft.
2.3 、Flux weakening compensation: only valid when the inner rotor motor type is selected as V-shaped
magnetic steel
Note: The maximum value of 255 is generally filled in 95
2.4、Three gear setting：Confirm the motor base speed value adjustment setting parameter value. The basic
speed is filled in according to the <Appendix EM_V3 Parameter Adjustment Calculation Formula>.
2.4.1、The low, medium, high, and third speed values are valid within 100% of the parameter value, and the
medium, high, and high speed values are exceeded and the 100% parameter value is filled. Exceeded by
weak magnetic file (medium, high, BOST)
2.4.2、In the flux weakening area, the actual parameters of the motor are adjusted, and the vehicle speed is
based on the road test.
2.4.3、Single voltage mode: The high voltage value is invalid.
2.4.4、Attention
2.4.4.1 、 Drum motor: 60KM/H motor weak magnetic speed is less than <120%, 80KM/H motor weak
