SIATA Aqua Timer Plus User Manual

Aqua Timer Plus - 24/34
6.5 – Remote Start
Aqua Timer Plus offers a “remote start” entry which allows for the regeneration to be started up by an external
automatism or by a button placed at a distance from the system. Whichever device is used, it normally open type, and
to start up the regeneration it must be closed for at least 15 seconds.
The regeneration by remote start can start both immediately and deferred to the programmed time, depending on what is
programmed in the flag 2HL.
6.6 – Programming of the litre counter divider ( prescaler )
The programming of the litre counter divider defines the ratio between the number of impulses read by Aqua Timer
Plus and the unit of load in transit in the counter used ( litres or m³) .
Aqua Timer Plus has two work modes:
 free prescaler if the flag 0CP is equal to 0; in this case the prescaler may be programmed within the range of
values 1  899 (n° of impulses given by the litre counter before the volume climbs by one unit);
 pre-programmed prescaler; in this case the litre counter dividers which can be used are those indicated in the
first column of table 24;
Tab.24 – Table of the pre-programmed litre counter dividers
Type of litre counter divider (impulses / litre)
Representation on the display
14 / 01
1 4.0 1
4 / 1
0 4.0 1
1 / 1
0 1.0 1
4 / 10
0 4.1 0
2 / 10
0 2.1 0
1 / 10
0 1.1 0
4 / 100
4.1 0 0
2 / 100
2.1 0 0
1 / 100
1.1 0 0
4 / 1000
4.0 0 0
2 / 1000
2.0 0 0
1 / 1000
1.0 0 0
