SIATA Aqua Timer Plus User Manual

Aqua Timer Plus - 16/34
6.2.3.c – List of codes to be programmed
For the programming and the meaning of the codes see par. 6.3. In this modality, the programming of the following
codes is recommended:
Tab. 14 – Table of the codes in one single column modality LLL1 – LL–3
Code
Meaning
SC02
Programming of the time of regeneration and of the interval days between two regenerations
SC03
Programming of the regeneration cycle ( stop times )
SC04
Programming of the litre counter divider ( prescaler )
SC05
Programming of the duration of the end of cycle impulse and of the litre counter divider of the dosing
pump
SC06
Programming of the volume of resin, of the percentage of reserve and of the exchange capacity
SC01
Programming of the hardness value
SC00
Initialisation of the system
6.2.4 – LLL2 – LL–1 – A duplex column with start by time.
6.2.4.a – Operative characteristics
In this operative modality, the regeneration starts exclusively at the programmed time after the interval days
programmed ( or on the days of the week selected ). No control is available on the volume or on the reserve. Control is
available on the remote start, which can start up the regeneration both immediately and deferred to the programmed
time, on the basis of the content of the flag 2HL. It is possible to use the cam with the stand-by. (see par. 6.8)
6.2.4.b – Programming of the FLAGs
Tab. 15 is to be used in the programming of the FLAG for the modality LLL2 – LL–1
Tab. 15 – Selection of the operative modality duplex column – start by tempo

FLAG
Display
Operative state / Data visualised
Program
S C - -
State of access to the selection of the programming codes
Advance
S C 0 9
With the key Advance the programming code is increased up to 9
Program
L L L 2
Modality duplex column. If necessary modify the data with Advance
Program
L L - 1
Regeneration a tempo. If necessary modify the data with Advance.
Program
0 H L
0 H L 0
FLAG not used
Program
1 H L
1 H L 0
Interval between two regenerations expressed in days. See par. 6.3.2
Advance
1 H L
1 H L 1
Regeneration to be carried out on the days of the week programmed.
Program
2 H L
2 H L 0
Immediate start of the regeneration at the command of the remote start.
See par. 6.5
Advance
2 H L
2 H L 1
Start of the regeneration at the programmed time on the command of the remote
start
