SIATA Aqua Timer Plus - Page 27

Aqua Timer Plus - 27/34
Tab. 25 – Time diagram of the standard regeneration cycle (Type 1).
1C
2C
3C
4C
Search of the stroke
end
Stop
Stop
Stop
Stop
Stroke end
Stroke end
= Movement phase of 25 seconds.
Tab. 26 – Time diagram of the standard regeneration cycle and cam with stand-by (Type 2).
Pos. of stand-by
1C
2C
3C
4C
Search of the stroke
end
Stop
Stop
Stop
Stop
Stroke end
Stroke end
= Movement phase of 25 seconds.
Tab. 27 – Time diagram of the regeneration cycle with stand-by (Type 3).
Stand-by
1C
2C
3C
4C
Search of the stroke
end
Waiting time
Stop
Stop
Stop
Stop
Stroke end
Stroke end
= Movement phase of 25 seconds.
