Installation and
Maintenance Manual
ABT 75 G / ABT 90
G
Installation and Maintenance
Manual
CB8-E

Table of Contents

Questions and Answers

  • M
    Mary JonesAug 6, 2025
    What to do if SIBRE CB8-E brake disc is slipping?
    • J
      joshuachandlerAug 6, 2025
      If the brake disc is slipping, it could be due to several reasons. First, ensure the braking torque is correctly adjusted according to the operating manual (OM). Second, check and adjust the reserve stroke as per the OM and monitor during operation. Third, if the contact pattern of the linings is too small, bed-in the linings against the rotating disc. Fourth, linings may be worn or the brake disc may have inadmissible scoring, in that case, replace the linings and/or brake disc. Finally, check the adjustment of optional features and readjust if necessary, if the brake is acting against a mechanical limit stop when closing.
  • J
    Jermaine BatesAug 16, 2025
    Why is there severe wear of lining in SIBRE CB8-E?
    • E
      Edwin HoustonAug 16, 2025
      Severe or uneven wear of the linings may occur if the brake is not mounted centrally or is jammed. Correct any misalignment to resolve this issue.
  • E
    Eric JimenezAug 26, 2025
    What to do if SIBRE CB8-E brake is instable when opened?
    • L
      Laura CastroAug 26, 2025
      If the brake is unstable when opened, it might be because of worn bushings from years of operation. In this case, return the brake to SIBRE for refurbishment.

Summary

General Instructions

Safety Directions

Safety Directions

Important safety measures and general precautions for operation and maintenance.

Symbols Used in Operating Instructions

Explanation of warning, caution, and note symbols to ensure safe understanding of manual content.

Technical Data

Description of CB8-E Brake

Overview of the CB8-E brake design, function, and main components for technical understanding.

Dimensions and Specifications

Detailed dimensional drawings and technical specifications for the CB8-E brake model.

Installation

Scope of Supply and Transport

Information regarding the items included in the delivery and guidelines for safe transport of the brake.

Pre-Installation Checks and Handling

Essential checks before installation and safe procedures for lifting and handling the brake unit.

Cleaning Procedures

Instructions for cleaning brake discs and mounting surfaces prior to brake installation.

Handling of Brake Linings

Proper procedures for handling brake linings to maintain their integrity and performance.

Mounting of the Brake

Step-by-step guide for physically mounting the brake onto the base frame or sub-construction.

Manual Release Operation

How to operate the manual release mechanism for the brake, including safety notes.

Adjustment of Reserve Stroke

Procedure for checking and adjusting the reserve stroke to ensure correct brake functionality.

Adjustment of Brake Torque

Method for adjusting the brake torque by modifying spring preload for optimal performance.

Limit Switches

Explanation of optional limit switch functions for monitoring brake status.

Removing the Brake

Procedure for safely disconnecting and removing the brake from its installed position.

Maintenance

Replacing Brake Linings

Detailed steps for replacing worn brake linings without dismounting the brake unit.

Component Replacement and Lubrication

Guidance on replacing other components, workshop repair recommendations, and lubrication needs.

Spare Parts Information

Listing of essential spare parts with article numbers for ordering and maintaining the brake.

Trouble shooting

Disposal
