Installation and Maintenance Manual
CB8-E
Contents
page
1 General Instructions 3
2 Safety Directions 3
2.1 Safety Directions 3
2.2 Symbols used in the operating instructions 4
3 Technical Data 5
3.1 Description 5
3.2 Dimensions 8
4 Installation 9
4.1 Scope of supply 9
4.2 Transport 9
4.3 To be noted before installation 9
4.4 Lifting and Handling 9
4.5 Cleaning the brake disc 10
4.6 Cleaning the mounting surfaces 10
4.7 Handling of brake linings 10
4.8 Mounting of the brake – initial setup on site 11
4.9 Manual release 13
4.10 Adjustment of reserve stroke 14
4.11 Adjustment of brake torque 15
4.12 Limit switches 17
4.13 Removing the brake 17
5 Maintenance 18
5.1 Replacing the brake linings 18
5.2 Replacing other components 20
5.3 Lubrication 20
5.4 Spare parts 21
6 Trouble shooting 22
7 Disposal 23
