Installation and Maintenance Manual
CB8-E
WARNING
The manual release is spring biassed to realize an auto-kickback functionality. The activated
manual release will jump back in its initial position automatically by spring force, when the
brake is released by solenoid the next time.
4. Tighten fastening bolts when brake is closed.
Mounting bolts for
housing
Fig. 6: Tightening torque for mounting bolts
CAUTION
The force transmission between the housing and the mounting surface should take place by
friction and not by the shear capacity of the mounting bolts. Therefore NO lubricant or other
compound must be applied between housing and mounting surface. The needed friction is
created by the clean, dry, lubricant free surface and by the accurate mounting of the bolts.
5. Connect the thrustor with the power supply.
CAUTION
Check the indications on the thrustor name plate before connecting it with the power supply.
6. Adjustment of brake torque: Check the installed brake torque. If necessary install the required
brake torque following the instructions in §4.11.
7. Adjustment of reserve stroke: The adjustment of the reserve stroke (see §4.10) is carried out
automatically by successive opening and closing the brake several times (approximately 40-50
cycles). Thus the readjusting unit sets the brake in working position.
8. Check by electronically opening of the brake, if the gap between brake linings and brake disc is
the same on both sides. Otherwise adjust the position of the brake. The permissible misalignment
for all brake axles is ± 0,1 mm
The brake is ready for operation now.
CAUTION
The brake linings and the disc must be free of oil and grease.
