CDF600-2200 | SICK 8015922/1CC9/2021-07-12 • Subject to change without notice • SICK AG • Waldkirch • Germany • www.sick.com6
8015922/1CC9/2021-07-12 ∙ 8M_DR ITL ∙ Printed in Germany (2021-07) ∙ All rights reserved∙ Subject to change without notice
Parameter Cloning (in the proxy mode)
In the same way as the optional CMC600 parameter
memory module (which can be installed in the CDB and CDM
connection modules), the CDF600-2200 eldbus module
provides an external parameter memory for the ID sensor
that supports proxy mode. When the parameter values in the
connected ID sensor are permanently saved (proxy mode 0),
the eldbus module also stores a copy of this parameter set
in its parameter memory.
This makes it easier to exchange the ID sensor in the event
of device failure because the new device of the same type
automatically loads the parameter set from the parameter
memory of the eldbus module. This means that manual
conguration is not required.
In the event of failure of the eldbus module, the ID sen-
sor which supports proxy mode automatically copies its
parameter set into the empty parameter memory of the
replaced, connected eldbus module of the same type after
initialization.
Maintenance and Care
With the exception of cleaning the transparent panels
covering the rotary encoding switches and status indicators,
the CDF600-2200 eldbus module is maintenance-free in
operation.
> In contaminated environments, the side cover with the
circular transparent panel covering the rotary encoding
switch and the transparent panels covering the status
indicators should be cleaned from time to time. Use a soft
cloth dipped in a mild cleaning agent for this purpose.
Transport and storage
Transport and store the eldbus module in the original pack-
aging, with protective plugs and caps completely screwed-on.
Do not store outdoors. To ensure that any residual moisture
present can escape, do not store the devices in airtight con-
tainers. Do not expose to aggressive media (e.g. solvents).
Storage conditions: Dry, dust-free, no direct sunlight, as little
vibration as possible, storage temperature -35°C to +70°C,
relative humidity max. 90% (non-condensing).
Repairs
Repair work on the eldbus modules may only be performed
by qualied and authorized service personnel from SICK AG.
Disassembly and disposal
Any eldbus module which can no longer be used at the end
of the product life cycle must be disposed of in an environ-
mentally friendly manner in accordance with the respective
applicable country-specic waste disposal regulations. As
they are categorized as electronic waste, eldbus modules
must never be disposed of with household waste. SICK AG
does currently not take back eldbus modules that are no
longer t for use.
Sources for obtaining additional information
The following sources of additional information about the
CDF600-2200 eldbus module, its optional accessories, and
SICK identication sensors are available in electronic format
on the corresponding SICK product pages on the web:
Fieldbus modules CDF600-2200
www.sick.com/CDF600-2
• Detailed technical specications (online data sheet)
• Technical information CDF600-22xx eldbus module
in German (no. 8015923) and English (no. 8015924)
• GSDML les for the ID sensors and the eldbus module
for integration in the IO controller
• EC declarations of conformity
• Dimensional drawing and 3D CAD dimension models in
various electronic formats
• Eplan connection diagrams (drawings)
• Suitable accessories (including cables, trigger sensors)
• Operating instructions CDF600-2200 eldbus module in
German (no. 8015921) and English (no. 8015922) as well
as in other languages if applicable
• Ordering information in the identication solutions product
catalog
SICK ID sensors that support proxy mode
e.g. CLV62x bar code scanner
www.sick.com/CLV62x
• Operating instructions
SICK ID sensors that support gateway mode
e.g. LECTOR
®
65x image-based code reader
www.sick.com/Lector65x
• Operating instructions
e.g. hand-held scanner:
1D hand-held scanner
www.sick.com/IDM14x
www.sick.com/IDM16x
2D hand-held scanner
www.sick.com/IDM24x
www.sick.com/IDM26x
• Operating instructions for the IDM1xx and IDM2xx hand-
held scanners
Support is also available from your sales partner:
www.sick.com/worldwide
