SICK DS35 User Manual

IO-Link interface
40 © SICK AG • Subject to change without notice • 8014868/YIF1/2020-10-19
1:Distancemeasuredvalue,OWSsignallevelwarning,alarm
3)
MSB
1)
LSB
2)
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Distance measured value (14-bit)
4), 5)
OWS
3)
Alarm
2:Level,OWSsignallevelwarning,alarm
3)
MSB
1
LSB
2)
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Signal level (14-bit)
3)
OWS
3)
Alarm
3: Distance (factory setting)
MSB
1
LSB
2)
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Distance measured value (16 bit)
5)
4:Distancevalue,signalquality
MSB
1
LSB
2)
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Distance measured value (14-bit)
4), 5)
Signal quality
(2-bit)
6)
5:Timer(onlyforExtendedversion
7)
)
MSB
1
LSB
2)
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Time measured value (16 bit)
5)
6:Timer,statusofswitchingoutputQ1andQ2(onlyforExtendedversion
7)
)
MSB
1)
LSB
2)
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Time measured value (14 bit)
4), 5)
Q1 Q2
1) Most signicant bit
2) Least signicant bit
3) → See Chapter 10.1 on page 49
4) For a congured resolution of, for example, 1 mm, and an available process data width of 14 bits, a maximum of 16,383 mm can be repre-
sented for the distance measured value. Higher values are output as 16,383 mm. If a very high resolution is required at a greater distance,
you can set an oset for the process data using index 107, "process data standardization".
5) Resolution selectable: 0.1 mm / 1 mm / 10 mm (via index 105)
6) Signal quality from 0 to 3. 0 = No signal or very weak signal; 1 = Sucient; 2 = Good; 3 = Excellent
7) → See Chapter 10.7 on page 54
Table 12: Process data structure
