9 Technical data
9.1 Technical data
Table 4: Features
Features
Variant with plug connector
Housing material Fiberglass-reinforced thermoplastic
Enclosure rating (IEC 60529) IP 67
Mechanical service life 1 × 10
6
S
witching operation with small load
B
10d
(EN IS
O 13849) 3 × 10
6
Switching operation with small load
Type Type 2 (EN ISO 14119)
Coding level of the actuator Low coding level (EN ISO 14119)
Ambient operating temperature –20 °C … +55 °C
Connection type Plug connector, 1 x M12 (8-pin)
Max. actuation speed 20 m × min
–1
Max. actuation frequency 1,200 × h
–1
Pollution degree
(e
xternal, according to EN 60947)
3 × (industry)
Max. actuating force at 20 °C 10 N
Max. force against which unlocking is possible 10 N
Max. retaining force, unlocked 20 N
Locking force F
ma
x
1,300 N
Locking force F
Zh
ac
cording to (EN ISO 14119)
(F
Zh
= F
max
/1.3)
1,000 N
Minimum door radius ≤ 1000 mm
Table 5: Electrical data
Electrical data
Variant with plug connector
Thermal current l
t
h
1 A
Switching principle Slow action switching element
Rated impulse withstand voltage U
im
p
1.5 kV
Utilization category (IEC 60947-5-1) AC-15: 24 V/1 A; DC-13: 24 V/1 A
Min. switching voltage
1)
12 V
Min. switching current at 24 V DC 1 mA
Conditional rated short-circuit current 100 A
Short-circuit protection (control fuse) (IEC
60269)
1 A gG
Solenoid supply voltage (+10% … –15%) AC/DC 24 V
Max. solenoid power 8 W
ED switch-on time 100%
1)
At 10 mA.
TECHNICAL DATA 9
8022168/2017-11-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i10 Lock
