1.2 Technical Specifications
1.2.1 IDM Corded Hand-held Scanners
Type IDM120 IDM140 IDM160 IDM240 IDM260
Field of
application
General Purpose General Purpose Industrial General Purpose Industrial
Enclosure
rating
IP 41 IP 41 IP 65 IP 41 IP 65
Supported
code types
1D, Stacked
1
1D, Stacked, 2D
1D, Stacked, 2D,
DPM
2
Code
resolution
≥0.102 mm
1)
≥0.076 mm
1)
SR model: ≥0.08 mm
1)
, ≥0.18 mm
2)
HD model: ≥0.08 mm
1)
, ≥0.13 mm
2)
Reading
distance
(at code
resolution)
0 mm ... 250 mm
(0.33 mm)
1)
50 mm ... 600 mm
(0.5 mm)
1)
50 mm ... 800 mm
(0.5 mm)
1)
SR model:
30 mm ... 155 mm (0.25 mm)
2)
HD model:
35 mm ... 90 mm (0.13 mm)
2)
Interfaces
USB (Keyboard Wedge & Com Port Emulation), RS-232 TTL, PS/2
(Ethernet TCP/IP, PROFINET, PROFIBUS, DeviceNet)
3
Optical
indicators
1 LED
(good read)
2 LEDs (operational status, good read)
Vibration No No Yes No Yes
Acoustic
indicators
Beeper, disengageable
Operating
Voltage
5 V DC (+/- 5%)
Current
consumption
(Operating)
Typical
170 mA
Typical 180 mA
180 mA
(Vibrator disabled)
230 mA
(Vibrator enable)
Typical 285 mA
Max. 285 mA
(Vibrator disabled)
Max. 335 mA
(Vibrator enable)
Current
consumption
(Standby)
Typical 75 mA Typical 80 mA Typical 90 mA Typical 160 mA Max. 150 mA
Light source LED: visible red light (630 nm)
Laser aimer No Yes (Laser Class 1)
Ambient
operating
temperature
0 °C ... 50 °C -20 °C ... 50 °C -10 °C ... 50 °C -20 °C ... 50 °C
Storage
temperature
-20 °C ... 60 °C -40 °C ... 70 °C -30 °C ... 70 °C -40 °C ... 70 °C -40 °C ... 70 °C
1)
Valid for Code 39,
2)
Valid for Data Matrix
1
Depending on scanner version (PDF version is necessary).
2
Depending on scanner version (DPM version is necessary).
3
Optional via external SICK connection modules.
