1.2.2 IDM Bluetooth Hand-held Scanners
Type IDM140 BT IDM160 BT IDM241 BT IDM261 BT
Field of
application
General Purpose Industrial General Purpose Industrial
Enclosure rating IP 41 IP 65 IP 41 IP 65
Supported code
types
1D, Stacked
1
1D, Stacked
1
1D, Stacked, 2D 1D, Stacked, 2D, DPM
2
Code resolution
≥0.076 mm
1)
≥0.076 mm
1)
SR model: ≥0.08 mm
1)
, ≥0.18 mm
2)
HD model: ≥0.08 mm
1)
, ≥0.13 mm
2)
Reading
distance
(at code
resolution)
50 mm ... 600 mm
(0.5 mm)
1)
50 mm ... 800 mm (0.5
mm)
1)
SR model:
30 mm ... 155 mm (0.25 mm)
2)
HD model:
35 mm ... 90 mm (0.13 mm)
2)
Interfaces
USB (Keyboard Wedge & Com Port Emulation), RS-232 TTL, PS/2
(Ethernet TCP/IP, PROFINET, PROFIBUS, DeviceNet)
3
Bluetooth
Protocol
Bluetooth v 2.1 EDR, 2.4 ... 2.4835 GHz Bluetooth v 4.0, 2.402 … 2.4830 GHz
Bluetooth
operating range
Up to 100 m (free view), Batch function for
expansion of the wireless radius
Up to 100 m (free view), Batch function for
expansion of the wireless radius
Optical
indicators
2 LEDs (good read, charge of battery, radio connection status)
Vibration No Yes No Yes
Acoustic
indicators
Beeper, disengageable
Operating
Voltage
5 V DC (+/- 5%)
Current
consumption
(Operating)
180 mA 230 mA (Vibrator enabled)
180 mA (Vibrator disabled)
300 mA 330 mA (Vibrator enabled)
300 mA (Vibrator disabled)
Current
consumption
(Standby)
80 mA 90 mA 180 mA 180 mA
Light source LED: visible red light (630 nm)
Laser aimer No Yes (Laser Class 1) No Yes (Laser Class 1)
Ambient
operating
temperature
0 °C ... 50 °C -20 °C ... 50 °C -10 °C ... 50 °C -10 °C ... 50 °C
Storage
temperature
-40 °C ... 70 °C -30 °C ... 70 °C -40 °C ... 70 °C -40 °C ... 70 °C
1)
Valid for Code 39,
2)
Valid for Data Matrix
For detailed technical specifications, see the Online Data Sheet on the product site on the web
(www.mysick.com/en
).
1
Depending on scanner version (PDF version is necessary).
2
Depending on scanner version (DPM version is necessary).
3
Optional via external SICK connection modules.
