SICK KTX Prime User Manual

Display Meaning
AdJ Alignment
AFc Automatic function
At Blanking
AUt Automated
blU Blue
bSY Busy
CoL Color
CoA Coarse
dAr Dark
dlY Delay
dSP Display switch
dYn Dynamic teach-in
Err Error
F-C Fine/coarse
FIn Fine
GrE Green
Job Parameter sets
Jo1 Parameter set 1
Jo2 Parameter set 2
Jo3 Parameter set 3
Jo4 Parameter set 4
Jo5 Parameter set 5
L-d Light/dark
LGt Light
LoA Load
LoC Locked
Mdl Middle
nF No function
oFF Off
OUT Output
PI1 Pin 1 configuration
PI2 Pin 2 configuration
PI5 Pin 5 configuration
Pro Pro level (advanced settings)
rEd Red
rES Reset
Sen Sensitivity
Sto Store
tch Teach-in
thr Threshold
toF Timer – OFF delay
ton Timer – ON delay
tP Pulse generator
